Acoustic Underlay Options
Acoustic Underlay Options

Select Underlay has a 2mm or 3mm EVA foam underlay, offering a superior higher density fabrication compared to a generic closed-cell foam. This ensures thermal and acoustic standards are exceeded for residential and commercial applications.



Perfect for both concrete and timber subfloors, Select Underlay offers peace of mind with up to 200mm extra-wide overlapped water-resistant 100um PE film, ensuring your floor is protected for years to come. Refer to our installation instructions for more information.

ComfortPro (2mm Acoustic Underlay)
Roll Area: 20m² / 50m²
Roll Diameter: 230mm / 380mm approx.
Weight: 5.8kg approx. / 14.5kg approx.
Roll Width: 1100± 1%
Thickness: 2mm
Density: 110kg/m³ approx.
Moisture Barrier: 80um polyethylene film
Overlap of Moisture Barrier: 100mm
Acoustic Rating: 5 Star (AAAC Rating)
Application: Floating floor (hardwood only)
Acoustic Pro (3mm Acoustic Underlay)
Roll Area: 20m²
Roll Diameter: 290mm approx.
Weight: 8.5kg approx.
Roll Width: 1100± 1%
Thickness: 3mm
Density: 110/m³ approx.
Moisture Barrier: 100um polyethylene film
Overlap of Moisture Barrier: 200mm
Acoustic Rating: 5 Star (AAAC Rating)
Application: Floating floor (hardwood only)
